Module TW DLE G2 60mm 3000lm 927-965

DLE modules

Product description

  • Tunable White system for Downlights with adjustable colour temperature from 2,700 to 6,500 K at constant luminous flux
  • High colour rendering index CRI > 90
  • High efficacy up to 136 lm/W for the LED module at tp = 65 °C
  • LED module for Downlight applications with 2,000 or 3,000 lm
  • Long lifetime of 50,000 h and 5 years system guarantee

Typical applications

  • Downlight for retail and corridor applications
  • Tunable white application
Autoscroll for tables
Ordering data
Type Article number Colour tempera­ture Packaging, carton Weight per pc.
TW DLE G2 60mm 3000lm 927-965 89603439 2,700 – 6,500 K 10 pc(s). 0.057 kg
Luminaire types:
Recessed floor & wallmounted luminaires
Linear luminaires
Wide-area luminaires (in-built, remote, pendant)
Approval marks:
ESD
CE
ENEC
RoHs
Technical data
Beam characteristic 120°
Ambient temperature ta -25 ... +55 °C
tp rated 65 °C
tc 95 °C
Irated 400 mA
Imax 700 mA
Max. permissible LF current ripple 770 mA
Max. permissible peak current 2,000 mA / max. 10 ms
Max. working voltage for insulation SELV (1) < 60 V
Insulation test voltage 0.5 kV
ESD classification Severity level 4
Risk group (IEC 62471) RG1
Classification acc. to IEC 62031 Built-in
Type of protection IP00
Lumen maintenance L70B50 50,000 h
Guarantee 5 Year(s)
Autoscroll for tables
Specific technical data
Type Channel Photo­metric code Useful luminous flux at tp = 25 °C (1) Expected luminous flux at tp rated (1) Typ. forward current Min. forward voltage at tp rated Max. forward voltage at tp = 25 °C Power con­sump­tion Pon at tp = 25 °C (1) Efficacy of the module at tp = 25 °C Expected efficacy of the module at tp rated Col­our ren­der­ing in­dex CRI
TW DLE G2 60mm 3000lm 927-965 WW 927/349 2,070 lm 1,941 lm 400 mA 38.0 V 42.1 V 16.3 W 127 lm/W 123 lm/W >90
TW DLE G2 60mm 3000lm 927-965 CW 965/349 – 2,189 lm 400 mA 39.0 V 43.1 V – – 135 lm/W >90
TW DLE G2 60mm 3000lm 927-965 WW 927/349 – 2,836 lm 600 mA 40.0 V 44.1 V – – 114 lm/W >90
TW DLE G2 60mm 3000lm 927-965 CW 965/349 – 3,005 lm 600 mA 41.3 V 45.5 V – – 117 lm/W >90
Document Size Date

Module_TW_DLE_G2_60mm_3000lm_en.pdf
Data sheet 		978 KB 28/03/2022
Leaflet_TunableWhite_EN.pdf
Leaflet Tunable White 		1.63 MB 23/03/2022
Certificates / declarations of conformity
Type      Article number      Certificates
Certificates ()

Certificates for ()

Document      Country      Size      Date of issue
new
Autoscroll for tables
CAD / RAY
Type Article number CAD Files
TW DLE G2 60mm 3000lm 927-965 89603439 CAD (3.7 MB)
EPD
Type Article number Environmental Product Declaration (EPD)
TW DLE G2 60mm 3000lm 927-965 89603439 EPD
